Broadcast 3G HD SD ASI Distribution Amplifier Harris DA-HR6802 1x8

Description

The Harris DA-HR6802 is a high-performance 3G/HD/SD video distribution amplifier, designed to excel in settings such as broadcasting, cable networks, production environments, and educational institutions. This robust device ensures reliable dual-channel signal distribution with advanced reclocking capabilities, offering a cost-effective solution without compromising on performance or quality.

Features

• Single input with eight robust outputs for versatile distribution
• Real-time signal presence detection and reporting
• Automatic input cable equalisation for seamless connectivity
• Adjustable maximum equalised cable length, applicable for 270 Mb/s
• Advanced selectable reclocking mode: automatic or manual settings
• Reclockable for 270 Mb/s, 1.5 Gb/s, and 3.0 Gb/s SMPTE signals
• Full compatibility with DVB-ASI signals
• Clear LED indicators display reclocking status and rate reporting
• Flexible reclocking bypass mode: automatic or enforced options
• Convenient card edge control via jumpers with user-friendly LED display
• Remote operation via RS-232 or Ethernet for ease of use

Specifications

• Model: DA-HR6802
• Input Types: 3G, HD, SD video signals
• Output Count: 8 channels
• Control Interfaces: RS-232, Ethernet connectivity
• LED Indicators: Signal presence, reclocking status, and data rate
• Cable Equalisation: Automatic for optimal connection
• Companion Accessory: HARRIS 170-0020265Q01 C 1 x 4 outs

What you get

• 1 x HARRIS DA-HR6802 Single 1x8 Distribution Amplifier 3G/HD/SD/ASI
• 1 x HARRIS 170-0020265Q01 C 1 x 4 outs
