Industrial Thermostat Dixell XT110D 230V Controller LED Display HVAC System

Industrial Thermostat Dixell XT110D 230V Controller LED Display HVAC System

The Dixell XT110D is a reliable and precise industrial thermostat designed for HVAC systems. It features a three-digit LED display with a decimal point, delivering high accuracy with a precision better than 1% at full scale. This thermostat supports various probe inputs including NTC, PTC, Pt100, as well as thermocouple types J, K, and S, making it versatile for different environments and applications.

Features

• 3-Digit red LED display for easy viewing
• Supports multiple sensor types: NTC, PTC, Pt100, TcJ, TcK, TcS
• First-stage relay outputs: no 8A/nc 5A
• TTL serial output for data communication
• Optional 4-20 mA analogue output
• Self-extinguishing ABS case for safety
• EEPROM memory for reliable data storage
• Compatible with a wide operating temperature range of 0°/60°C

Specifications

• Power Supply: 230V AC
• Display Type: Red LED (13 mm height)
• Storage Temperature: -30°/85°C
• Relative Humidity: 20-85%
• Connections: Screw-on terminal block for wires <2.5mm²

What you get

• 1 x Unit
• 1 x Power Supply
• 1 x Battery Charger
• 1 x Power Cable
